NEW Heming

Available from 5W-60W

Heming is a traditional heritage lantern designed to bring character to modern lighting schemes. A top-entry, cradle mounted teardrop lantern, it reflects familiar architectural styles found across UK streets, conservation areas and historic town centres.

Behind the traditional form, Heming integrates modern LED performance, delivering efficient, controlled light distribution suitable for a range of applications. With colour temperature options including 2200K and 2700K, it supports projects where reduced blue light and sensitive lighting design are key considerations.

Specifications
https://www.trtlighting.co.uk/wp-content/uploads/2023/08/cta-bg.jpg

Contact us

Get in touch

Contact us for a quote today

Discover our exterior lighting solutions designed for energy efficiency and sustainability. Request a comprehensive quote tailored to your project needs today.

Get a Quote

Downloads

Photometry

For photometric data, please email photometry@trtlighting.co.uk

Specification

Specifications

  • LED colour temperature 2200K, 2700K, 3000K or 4000K
  • Colour rendering index >70
  • Projected L90 after 100,000 hours
  • Power factor >0.95 at full load
  • Robust spun aluminium canopy
  • Black polyester powdercoat body with white LED reflector
  • Stainless steel fixings
  • UV stable polycarbonate classic teardrop bowl
  • High efficiency PMMA lenses
  • CLO available
  • Zhaga Book 18 (SR) socket (top with cap) (optional)
  • DALI-2 and D4i certified control gear for use with CMS and external sensors/devices
  • Drop down plate hinges to access sealed LED compartment
  • Simplified maintenance with tool-less access
  • Recommended mounting height of 6m-12m
  • UMSUG codes available for full product range

Range Overview

 Heming 24 LED Heming 48 LED
System Power 5-30W 30-60W
Road Optics
Area Optics
LED CCT 2200K, 2700K, 3000K or 4000K
Lumen Output Up to 5,568m Up to 10,969lm
LED CRI >70

Electrical Characteristics

Heming 24 LED Heming 48 LED
System Power 5-30W 30-60W
LED CCT 2200K, 2700K, 3000K or 4000K
LED CRI >70
Lumen Output Up to 5,568lm Up to 10,969lm
Lumen Maintenance Projected L90 after 100,000 hours
Drive Current 80-627mA 313-630mA
Driver Output Constant current (with AM dimming)
Power Factor
(Full Load/Half Load)		 0.95/0.90
Operational Voltage 220-240VAC rms
Operating Frequency 50/60Hz
Inrush Current
(Apk/50%-µS)		 25A/236µS 32A/355µS
Running Current
(Max)		 130mA 260mA
Surge Protection
(COM/DIF)		 10kV/6kV
Lighting Controls Options Zhaga Book 18 (SR) socket (top with cap) and PND
Dimming Protocols DALI, D4i

Mechanical Characteristics

Housing Material Spun aluminium (Grade 1050)
Cover Material UV stable polycarbonate
Lens Material PMMA
Housing Finish Black polyester powdercoat
Ingress Protection Rating IP66
Weight Up to 12kg
Wind Area 0.22m²
Impact Resistance Rating IK08
Mounting Method Cradle mount – top entry 1 or 1 ¼” thread
