NEW Altura Anti-Climb
5W-8W Available
Engineered for safety and versatility, the Altura Anti-Climb light is a standalone, anti-access lighting unit ideal for high-risk or sensitive public areas. Crafted from robust grade 304 (also available in grade 316 marine grade stainless steel), it comes in three lengths and supports both Altura Midi and Altura Maxi LED modules. The angled design deters climbing, while tamper-proof screws ensure security.
With a sleek, low-profile look, it integrates seamlessly with structures like station footbridges or palisade fencing. Features include dimmable or DALI control, 3hr battery back-up, and customisable mounting. With a standard finish of any warm-to-touch RAL polyester powder coat (satin/brushed, bead blasted and bespoke finishes are optional), the Altura Anti-Climb light is built to last – with a 5-year warranty.
-
70mm x 100mm
Diameter -
IK10
Impact Resistance -
IP66
Ingress Protection -
LED
Light Source -
Up to 200
Lux Levels -
304
Stainless Steel
Contact us
Get in touch
Contact us for a quote today
Discover our exterior lighting solutions designed for energy efficiency and sustainability. Request a comprehensive quote tailored to your project needs today.
Photometry
For photometric data, please email photometry@trtlighting.co.ukSpecification
Specification
- Angled design to prevent a foot or hand hold
- Available as individual units or as a continuous length
- Compatible with both Midi and Maxi LED modules
- LED colour temperature PC-Amber, 2200K, 2700K, 3000K or 4000K
- Colour rendering index >80
- Rated life of 50,000 hours
- Stainless steel (grade 304) (also available in grade 316 marine grade stainless steel)
- Standard warm-to-touch RAL polyester powder coat finish (satin/brushed, bead blasted and bespoke finishes are optional)
- Clear or diffused lens option
- Impact resistant polycarbonate LED module
- Asymmetric distribution
- Ambient temperature 25oC
- On/off or DALI lighting controls
- Dimmable or non-dimmable driver options available
- Emergency feature – 3hr battery back-up
- Parallel connection – all modules continue to function if one fails
- Multiple fixings available
- Vandal resistant tamper-proof screws
- Simple installation and maintenance
Range Overview
| Range | Length | Qty of LED modules |
|---|---|---|
| Altura Anti-Climb individual 495mm unit | 495mm | 1 per unit |
| Altura Anti-Climb individual 1500mm unit | 1500mm | 2 or 3 per unit |
| Altura Anti-Climb continuous handrail | Made to length sections | 1 to 3 per section |
Electrical Characteristics
| Altura Anti-Climb | |
|---|---|
| System Power | 5-8W (emergency circuit adds 0.29W) |
| LED CCT | PC-Amber, 2200K, 2700K, 3000K or 4000K |
| LED CRI | >80 |
| Operational Voltage | Stabilised 24V DC ± 5% |
| Luminaire Lumens (Clear Lens) | Up to 710lm |
| Lumens Per Circuit Watt | Up to 89lm/CW |
| Dimming Protocols | DALI or 0/1-10V |
| Additional Options | Emergency 3 hour back-up |
Mechanical Characteristics
| Module Dimensions | 140mm x 22mm diameter (Altura Midi)
300mm x 22mm diameter (Altura Maxi) |
| Handrail Material | 304 marine grade stainless steel |
| Handrail Finish | Standard warm-to-touch RAL polyester powder coat finish (satin/brushed, bead blasted and bespoke finishes are optional) |
| Lens Material | Polycarbonate |
| Mechanical Fixing | Multiple fixings available |
| Ingress Protection Rating | IP66 |
| Impact Resistance Rating | IK10 |
| Standard | UKCA, CE and BS EN 60598-1 |
